Galvanized Wire Mesh

Galvanized is not a metal or alloy; it is a process in which a protective zinc coating is applied to steel to prevent rusting. In the wire mesh industry, however, it is often treated as a separate category because of its wide spread use in all types of applications. Some of the more popular uses and applications of galvanized wire mesh are listed below:

  • Fencing, caging & enclosures
  • Farm, garden & agricultural use
  • Window & safety guards
  • Archeological use
  • Building & construction projects
  • Infill panels
  • High security applications
  • Landscaping & gabions
  • Wall & stone retention
  • Greenhouse use
  • Particle separation
  • General industrial use

Galvanizing can occur either before or after wire mesh is manufactured – both in woven form or welded form. Galvanized before woven wire mesh or galvanized before welded wire mesh indicates the individual wires, themselves, used to manufacture the mesh have been galvanized before the mesh is woven or welded. Depending on the mesh (or opening size) and diameter wire, this is usually the less expensive option, especially if custom manufacturing is required.

Galvanized after woven and galvanized after welded wire mesh is exactly as it sounds. The material is manufactured, normally in carbon or plain steel, and is often placed in a galvanizing tank, thereby producing a galvanized after woven or welded specification. Generally speaking, this option is more expensive, depending on availability and other variables, but does offer a higher level of corrosion resistance. This added level of corrosion resistance is most noticeable at the joint or intersection of galvanized after welded wire mesh specification.

One of the main benefits of a galvanized wire mesh, and particularly of a galvanized welded specification, is that it tends to offer a wide variety of opening sizes and diameter wires. For instance, mesh opening sizes, such as 4” x 4”, 2” x 2”, 1” x 1” and ½” x ½”, tend to be readily available from stock in a handful of popularly requested diameter wires.

Due to its attractive price point and its corrosion resistance, galvanized wire mesh is very popular among industrial users of wire mesh. Usually, galvanized wire mesh is specified in applications where relatively large opening sizes are needed. Keep in mind that galvanizing a relatively fine mesh, after it is woven, is likely to clog the openings rendering it unusable in numerous applications. It is for this reason that, usually, a 10 x 10 mesh and finer will be manufactured as a galvanized before woven item.

Darby also stocks and distributes a wide array of vinyl coated welded wire mesh specification. Please contact us for more information.

Choose your Mesh:

From 4” x 4” Mesh to ¾” x ¾” Mesh

Galvanized Wire Mesh

Many of galvanized mesh specifications featured here consist of relatively larger opening sizes, ranging from 4” to ¾”. These items are available from stock or can be quickly manufactured, depending upon the customer’s requirements.

From 2 x 2 Mesh to 3 x 3 Mesh

Galvanized Wire Mesh

These galvanized mesh specifications are available from stock – particularly the more commonly requested items – or can be custom manufactured, depending upon a customer’s requirements.

From 4 x 4 Mesh to 10 x 10 Mesh

Galvanized Wire Mesh

These galvanized mesh specifications are available from stock – particularly the more commonly requested items – or can be custom manufactured, depending upon a customer’s requirements.


From 12 x 12 Mesh to 18 x 18 Mesh

Galvanized Wire Mesh

These galvanized mesh specifications are usually available from stock – particularly the more commonly requested items – or can be custom manufactured, depending upon a customer’s requirements. These items tend to be galvanized before woven specifications.

From 20 x 20 Mesh to 30 x 30 Mesh

Galvanized Wire Mesh

These galvanized mesh specifications are usually available from stock – particularly the more commonly requested items – or can be custom manufactured, depending upon a customer’s requirements. These items tend to be galvanized before woven specifications.

Vinyl Coated Wire Mesh Items

Vinyl Coated

Vinyl coated wire mesh specifications offer a highly level of corrosion resistance and remains popular selection in a wide range of applications.

From 4.00” to 1.313”

Galvanized Wire Mesh

When choosing a mesh for a specific application, determining the appropriate opening size is essential. These galvanized meshes offer relatively large opening sizes, spanning from 4” to 1-1/4”.

From .937” to 0.228”

Galvanized Wire Mesh

When choosing a mesh for a specific application, determining the appropriate opening size is essential. These galvanized meshes offer opening sizes from 1” to 1/4” and remain extremely popular among all types of users.

From 0.225” to 0.0603”

Galvanized Wire Mesh

When choosing a mesh for a specific application, determining the appropriate opening size is essential. These galvanized meshes range in opening size from approximately 1/4” to 1/16”.


From .0544” to .030”

Galvanized Wire Mesh

When choosing a mesh for a specific application, determining the appropriate opening size is essential. These galvanized meshes range in opening size from approximately 1/16” to 1/32”.

From .028” to .021”

Galvanized Wire Mesh

When choosing a mesh for a specific application, determining the appropriate opening size is essential. These galvanized meshes range in opening size from approximately 1/32” to 1/64”

Plain Weave/Plain Crimp

Galvanized Wire Mesh

Plain Weave/Plain Crimp is considered the standard for mostly all galvanized wire mesh specifications.

Intercrimp or Lock Crimp

Galvanized Wire Mesh

Intercrimp or Lock Crimp is a very popular weave/crimp type for custom manufactured galvanized woven wire mesh. It is usually reserved for opening sizes of 1/2" or larger.

Welded

Galvanized Wire Mesh

Galvanized welded wire mesh specifications are extremely popular among many different types of users.

Hexagonal

Galvanized Wire Mesh

Hexagonal construction is generally reserved for a specific product known as Chicken Wire
